Rotational Motion - Lab Report Example

Comments (0) Cite this document
Summary
The author of this lab report "Rotational Motion" aims to demonstrate how a constant torque can create angular acceleration on a rigid body rotating about its center of mass. Reportedly, according to laws of linear motion, a stone dropped into a well covers a distance given by equation 1 below…
Download full paperFile format: .doc, available for editing
Polish This Essay91.1% of users find it useful
Rotational Motion
Read TextPreview

Extract of sample
"Rotational Motion"

Download file to see previous pages The mass and dimensions of the steel block were measured together with the errors due to measurement. The Data studio (DS) data acquisition program was opened and a file Desktop-pirtlabs-PHY 122-Rotational motion. The file was preset to record θ (t) and ω (t).
Part I: The block was attached through its shortest axis onto the rotary encoder. The string was put on the medium pulley and wind it up entirely in a direction so it will unwind CCW (counterclockwise) when facing the pulley. The readings were taken.
Therefore, the dynamic moment of inertia along the short axis is greater than one for the long axis. However, the theoretically calculated static moment of inertia lies within the range defined by the dynamic moments of inertia calculated practically. It is, however, important to notice that the dynamic moments of inertia obtained are of the same order with Id for medium pulley through short axis (Id = 1.66 * 10-4) being slightly higher for the long axis (Id = 1.52 * 10-4). The moments of inertia obtained are affected by the distribution of mass from the center of mass of the object used. Thus, accurate and precise measurement of parameters that determine the moment of inertia can produce results that are close to the absolute results predicted through a theoretical approach. ...Download file to see next pagesRead More
