Task: Computer sciences and Information technology   Practical Storage Management Introduction Practical storage management is all about assessing the online storage system and ensuring that all the entire process of storing data, information in documents, folders and files are well protected and reliable. The process of practical data storage is very complex and involves a lot of activities and operations such as data organization, device concept, data management and tools among others (Crotty et al. 19). The ultimate aim of this context is to examine the entire process of practical storage management. This context entails looking at the entire process of data organization, which includes base data objects, integrated database support, device concept, data management and tools, backup and recovery planning and native save (Gray and Reuter 23). Data Organization on AS/400 System It should be noted that all data on an AS/400 system is arranged using an object-centered approach. The following sectors discuss in more detail these themes (Kembel 33). I. Base data objects on an AS/400 system II. AS/400 built-in database support III. AS/400 integrated File System (IFS) Base Data Objects on an AS/400 System All things that can be kept or regained on the AS/400 system is kept in an object. There are several distinct object types like files, libraries, queues, executable programs, user profile, and others. Every substance has certain common attributes like type, name size, data developed, description, and owner (Milne, Potter and Avenell 113). The object-leaning concept permits the system to undertake some standard operations, like authorization management on all substance types, in the same manner. Besides, as already mentioned, it complains of AS/400 information against accidental corruption, since only operations linked with the determined substance type are permitted. In order to systematize AS/400 substances additionally, all substances are held in a library. A library refers to an OS/400 substance of type *LIBRARY, that is employed to group other substances jointly. Libraries are systematized at a one-level hierarchy, unlike the directory structure acquired on personal computers or in the UNIX operating system, which have a multi-level pecking order (Handoll, Cameron, Mak and Finnegan 83). This clearly implies that no library can hold another library substance, with a single exemption, the QSYS system master records. This is the main library that holds all the other libraries on the AS/400 system. Essentially, there are three distinct types of libraries: QSYS – system master library, system supplied libraries (all IBM-supplied library names begin with Q or #) and user described libraries (Kroenke and David 62). To locate an AS/400 substance, it is orientated by the library name and the substance name (LIBRARY/SUBSTANCE). An individual also requires the substance type to extra ordinarily recognize the object. Two or more substances can possess similar name, but they must be of distinct types (Kembel 51). This means that in a library, there can be a program termed as MAY and a data file (physically file) termed MAY, but there cannot be two agendas with similar name as MAY. Moreover, a substance can only be present in one library. Among all these substances, there is a substance of type *FILE, also referred to as a physical file, that holds data in the form of database, a device data, or a selection of associated libraries that are controlled as an entity (Gray and Reuter 23). These substances are split into two elements: the data illustration, employed to define the substance, and the data portion, which holds the real data kept on the system. A substantial file is a record-oriented, and data documents can be arranged into members within a substantial file. A substantial file can hold one or more affiliates. These affiliates are not substances themselves; rather, they are separations of an object (Crotty et al. 41). This clearly shows that all affiliates of a substance share similar essential characteristics with other affiliates of the substance, like possession and security. AS/400 integrated database Support To handle massive quantities of data, (such as the information acquired in a telephone book) competently, it is essential to arrange the data in a systematic way (Handoll, Cameron, Mak and Finnegan 99). In a computer machine, a keenly arranged group of information is referred to as database. A database issues a tool and data arrangements employed to manage, organize and operate with massive quantities of likely-arranged information. The database is intensely imbedded in the scheme architecture on an AS/400 scheme. The operating system OS/400, operates jointly with the SLIC layer to issue a build-in folder (Benner and Alan 246). The reality that the AS/400 folder, termed DB/2 for AS/400 is modeled into the essential operation of the AS/400 scheme positions it separately from several other computing schemes. Other machines require to have detached application packages to manage folders. There are numerous means of arranging the information in a database, depending on how you plan to employ this information (Codd 377). The AS/400 folder is applied as a relational database. Every piece of information in a relational database is associated to others using a tabular arrangement. With the arrangement, information is systematized in records and fields, exactly as it appears in a telephone book. For instance, in a telephone book, the entire information associated to one individual – name, telephone number, and address – is similar to a record (Seltzer 63). Moreover, the entire information solely associated to telephone numbers, names or addresses is equivalent to a field. The figure below clearly shows the structure of an AS/400 relational database. Since the AS/400 database is intensely incorporated into the architecture of the scheme, it is also employed to keep all the scheme data. The Integrated File System The incorporated file system is a section of an OS/400 program, starting with Version 3 Release 1 that integrates all kinds of information kept on AS/400 schemes. This information encompass files and folders (file schemes that have beforehand operated on AS/400 schemes), fresh file schemes equivalent to those acquired on personal computers and UNIX OS, as well as the support of stream files and several others (Handoll, Cameron, Mak and Finnegan 175). The integrated file organization incorporates the entire information distinctly kept data by issuing one boundary and one technique of admission to it. To the final user, it seems as one set of user boundaries (rule, menus, and displays) and submission program boundaries, which can mingle with substances in any file organization that has admission through directory arrangements (Gray and Reuter 23). The main concepts of the integrated file system are: I. Support for keeping of information in tributary files that can hold long continuous cords of data. II. A hierarchical directory organization that permits substances to be arranged as leaves on the tree branches. III. An ordinary boundary that permits users and submissions to have admission not only to the stream files, but also to documents, database files, and other substances that are kept in the AS/400 scheme (Crotty et al. 56). IV. An ordinary observation of stream files that are kept regionally on the AS/400 scheme. They can as well be kept locally on a LAN server. The integrated file system has several merits but the main one is the fact that it issues fast admission to OS/400 data, particularly for submissions like Client Access, that employ the OS/400 file server (Kembel 79). Support files system on an AS/400 System A file scheme issues the support that permits users and submissions to have admission to precise sections of storage that are arranged as logical joints. These rational joints are files, libraries, directories and substances/objects (Kroenke and David 62). Every file scheme has a set of rational arrangements and principles for mingling with information in storage. Moreover, from the perspective of arrangements and principles, the OS/400 holds up for admission to database files and several other object types via libraries can be believed to be similar to file scheme (Milne, Potter and Avenell 113). Likely, the OS/400 holds up for admission to documents (that are actual stream files) via the folders arrangement may be believed to be a distinct file scheme. He integrated file system actually treats the library support and folder support as distinct file schemes. Other types of file control support that have distinct abilities are also handled as distinct file schemes. These file systems include root which has characteristics of the Disk Operating System (DOS) and OS/2 file scheme, QOpenSys, QSYS.LIB, QDLS, QFileSvr.400, QOPT, QLANSrv, UDFS and NFS among others (Handoll, Cameron, Mak and Finnegan 209). This is clearly depicted on the following diagram, which shows an integrated file system. AS/400 Device Concept The input/output (I/O0 devices like workstations, disks, and tape drivers are fastened to an AS/400 scheme via an I/O processor inhabiting on an adapter card and I/O bus (Seltzer 78). The I/O processor is liable for administering the fastened devices. This clearly implies that all the I/O data to and from an interior device is shock absorbed on an AS/400 scheme. The I/O processor works with groups of data that are fully independent from the basic processor. Only sure I/O signs propel an interrupt to the CPU (Benner and Alan 246). A device can be fastened directly to an I/O adapter card; or it may be fastened to an exterior manager, which, in turn, is fastened to an adapter card. The controller may be capable of fastening several devices. The OS/400 substance employed to illustrate a device is referred to as a device description (DEVD) and the OS/400 object employed to illustrate a controller is referred to as controller description (CTLD). Instead of only being regionally fastened to the scheme, devices and controllers can be distantly fastened to the system (Crotty et al. 82). Whereas arranging devices with OS/400, you are not permitted to install divided device drivers for distinct devices as it is done in PC and UNIX surroundings. With OS/400, this hold up is incorporated into the OS (Lightstone, Teorey and Nadeau 291). OS/400 undertakes the automatic arrangement of the regionally fastened devices and is managed by system value QAUTOCFG. Starting with OS/400 V4R3, the control, WRKMLBRSCQ has been affixed to show requests that are pending drive evaluation and permit alteration of strictures (Benner and Alan 246). For instance, if a daily backup job usually functions at priority 50 but requires to be quickened on a particular day, the MLB job characteristics can be altered while the tape operation is still in the queue. The following figure shows a media library resource queue for an mechanized tape library termed as TAPMLB06 (Codd 379). AS/400 Data Management Concepts and Tools The AS/400 scheme issues inclusive notions and processes to control and guard data kept on an AS/400 scheme. The following section issues a short introduction to backup and recovery planning using regional tools and processes (Milne, Potter and Avenell 113). Backup and recovery planning using AS/400 Procedures When looking at computing surrounding or business requirements, it will be noted distinct approaches and processes planning backup and recovery. This section looks at these two concepts keenly. To begin with, arranging for a backup depends on certain factors like how frequent data changes on the system, hardware employed (disk space, tape drives), the quantity of data to be baked up, the time period required and the time window that business procedures permit for backup functions. Another significant factor is the time required for the restore process (Kembel 111). The AS/400 issues a set of backup techniques that can house all these requirements. Before employing these backup techniques, there is the need to regard distinguishing data into dynamic data (that changes frequently) and static data (that is not changing frequently). Static data can be saving on a weekly basis or monthly system. Unlike the static data, dynamic data should be saved on a daily basis. Selecting one process or another affects the manner through which data has to be restored, when required (Benner and Alan 246). For instance, saving all the data on a daily basis may need the tapes from the last backup to restore. If save only modified substances each day of the week, and a complete backup during the weekend leads to more restore works. To begin with, recover data from the weekend backup tape, then recover Monday’s backup data, then Tuesday’s, and so on, until the last backup holding modified objects. Other restrictions that affect backup times include: I. Whether a file is saved directly to magnetic tapes; to a save file that is a substance on disk; or to optical disks II. Whether substances are saved while they are being used, which can be conducted with save-while-active operation (Codd 378) III. Whether different concurrent backups are run to distinct tape drives, which can considerably minimize backup time. IV. Whether data compactness is used, data compaction or the optimal block size, a restriction that accelerates saves to tape drives supporting this operation (Lightstone, Teorey and Nadeau 291) Disaster Recovery A disaster recovery of an AS/400 scheme only operates possibly through the use of backup tapes. OS/400 issues no reports or lists of tapes holding the most current backups to assist in recovery system. Therefore, this tape inventory must be managed manually to realize what types are required. Alternative 21 from the SAVE menu permits the saving of the whole system (Handoll, Cameron, Mak and Finnegan 281). This alternative saves in succession: licensed Internal Code, System Library (QSYS), Security substances, encompassing user profiles, device configuration substances, all PC supplied libraries, all user libraries, all mail, all folders, documents, and object directories. The alternative 21 modifies the system mode to restricted mode to make sure no other function working on the system will stop the backup from completing (Seltzer 276). Native Save/Restore Commands The AS/400 scheme issue its own position of controls to back up substances from disk to tape or to a save file, or to recover substances to disk. All controls have non-payment values, which can be easily overridden. These two main commands are backup operations whose save command usually has similar prefix: SAV and restore operations which also employ same configuration beginning with the RST prefix (Milne, Potter and Avenell 113). Backup, Recovery, and Media Services/400 BRMS/400 – is a submission program that permits the user to organize, control and automate backup, recovery, and media management services for the AS?400 scheme. It permits the user to describe policies for backup, recovery, retrieve, archival, hierarchical storage management (HSM), and media tailor backup restoration and media movement arrangement that fulfills the business requirements. The following diagram imparts an overview of the BRMS/400 functionality (Benner and Alan 246). BRMS/400 Architecture and Entities This system presents a set of units that permits the user to describe policies for backup, media management and retrieve; and to modify a backup, recovery, and media strategy that specifically meets the requirements of the business (Gray and Reuter 123). The most common BRMS entities include control groups, media policies, devices and media classes, movie policy and storage location (Milne, Potter and Avenell 113). The following figure shows the main BRMS entities used to implement backup and recovery processes within BRMS/400. (Codd 381) The last data management concept and tool is BRMS/400 operation, which is responsible for illustrating save, or archive operation BRMS/400. This is clearly summarized on the diagram below. (Seltzer 311) Work cited Benner, Alan F. Fibre Channel. McGraw-Hill, New York, 2006. Print. Codd, E.F."A Relational Model of Data for Large Shared Data Banks". In: Communications of the ACM 13 (6): 377–387, 2001. Crotty M, Unroe K, Cameron ID, Miller M, Ramirez G, Couzner L. P2P Storage Systems Cochrane Database of Systematic Reviews 2010, Issue 1. Art. Gray, J. and Reuter, A. Transaction Processing: Concepts and Techniques, 1st edition, Morgan Kaufmann Publishers, 1999. Print Handoll HHG, Cameron ID, Mak JCS, Finnegan TP. Multidisciplinary Backup and recovery planning and tools. Cochrane Database of Systematic Reviews 2009, Issue 4. Art. Kembel, W. The Practical Program Storage, Northwest Learning Associates, Tucson, AZ , 1999. Kroenke, David M. and David J. Auer. Database Concepts. 3rd ed. New York: Prentice, 2007. Lightstone, S.; Teorey, T.; Nadeau, T. Physical Database Design: the database professional's guide to exploiting indexes, views, storage, and more. Morgan Kaufmann Press. 2007. Print. Milne AC, Potter J, Avenell A. Bio-Inspired Data Placement in Peer-to-Peer Netowrks. Cochrane Database of Systematic Reviews 2009, Issue 2. Seltzer, M. Beyond Relational Databases. Communications of the ACM, 51(7), 52–58. 2008. Read More
