The System Design of the News Collection Center - Statistics Project Example

1. Introduction 2 2. Background 2 3. System Specifications 4 4. Layout of the Studio 6 5. Model news room 7 6. Facility Design 8 7. TV tape archiving 9 8. Tape transmission 10 9. Means of conveying commentary and Text 11 10. Audio Video synchronization 12 11. TV station technology 13 12. Studio Equipment 14 13. Cost summary 15 14. Gant chart 18 15. References 18 1. INTRODUCTION PURPOSE The New sat, one of the largest network provider of the U.S from the past 10 years, is going to set up 60 broadcast channels in U.K to cover the European community. According to its announcement made with reference to Tender NO-172, New sat has set up a consortium with 60 broadcasters. The current technical document is a broad outlay of requirements to set up the News collection center and its major functionalities 1.2 BACKGROUND: The proposed news collection center is planned to be established at U.K with broad casters at Scandinavia, Southern Spain, Italy, Germany and Austria. The main functions of the News collection center as follows: The news collection center at Stockbridge in the U.K will transmit and receive information from the broadcasters. The main news collection center will receive compiled news material and raw stories from Europe in the form of rich text, Audio and video from the broadcasters The News studio will transmit the compiled material to the US and European compiled material to Europe The below diagram is a schematic representation of the entire context of the proposed system from stock bridge to European and other centers. NEWSAT Transmission Receiving Spain Scandinavia Germany Italy Other European centers News Collection center at Stockbridge, U.K Fig1:The Context Diagram of satellite communication between News Room and Broadcasters 2. SYSTEM SPECIFICATIONS OF THE NEWS STATION: 2.1 Transmitting Equipment: The major components in a transmitting chain consist of Transmitter, Antenna, Feeder Cable and Tower. Various combinations can, therefore, be worked out to suit individual requirements and keeping in view the availability of funds. These combinations will, however, revolve around the following parameters. Location : Stockbridge .U.K Dish : Dual Band Feed (C and KU Downlink Frequency : 3642 MHZ Polarisation : Vertical or Horizontal or Circular Symbol Rate : 19531 Msym/Sec FEC : ¾ 2.2 Receiving site equipment: The basic equipment needed by the receiving side of the TV station includes DISH, POLAR MOUNT, POSITIONER, LNB, FEED ASSEMBLY, SATELLITE CABLES, RECEIVER, and DESCRAMBLER. The diagram given below show the equipment involved in transmission of signals from geo stationary to Earth station with for TV receiver. DOWNLINKING UPNLINKING Fig2: The transmission control from GEO stationary to Earth station 2.3.LAYOUT OF THE STUDIO: The proposed system of TV studio is planned to set up an acoustic layout of STUDIO CONTROL ROOM VIDEO OPERATING ROOM TRANSMITTER ROOM The E-R diagram illustrates much about the design as follows: MIC Monitor Speakers STUDIO CONTROL ROOM VIDEO OPERATING ROOM TRANSMITTER ROOM Fig3. BLOCK DIAGREAM OF THE PROPOSED TV STUDIO LAYOUT 2.4.A MODEL NEWS ROOM INTERFACE WITH 4 CHANNELS: Source from http://www.clearcom.com 2.5.FACILITY DESIGN: The above layout is supposed to accommodate the following facility 2.5.1.Television control rooms: According to the world-class renowned technologies it is intended to develop the defined equipment requirements and developed mirror-image ergonomic layouts of the control rooms. Cooling and lighting level requirements were based on the control rooms each containing 60 monitors at 4:3 aspect ratio monitors with an expected 30 percent expansion capability. Six-inch risers separate front- deck and rear-deck operations while resting on computer flooring placed 18 inches above slab. The audio control rooms, located within each studio control room area, were designed for 5.1-channel surround sound ergonomics and acoustics for the later implementation of AC-3 audio. 2.5.2.Television master control room: The master control room’s “control point” area provides operating positions for four individuals. Master control can operate the channel 2 NTSC and channel 60 local TV stations at 720p 16:9, ultimately from a single switch. The room architecture provides stations for individuals to control multichannel, second-signal digital revenue stream opportunities. 2.5.3.Television central rack room: A 1500-square-foot room houses 60 broadcast racks. The first row bay is separated by glass and serves as the swing point of tape transition to nonlinear server technology. The Next row is supposed to accommodate large digital routing switcher and electronics that feed all news operations. Central rack room and tech core space is serviced by isolated fifth-wire grounding, generator and UPS-regulated power. 2.5.4.Television cable management: One of the most significant aspects of the TV signal design is the elaborate cable management program. All broadcast systems integration cabling is planned to be separated by its own engineering discipline (e.g. video, audio, intercom, IFB, etc.), with special attention to the separation of telephone. 2.5.5.Electricity: Power is planned to provided through dual neutral feeders from the electrical switchboard and K-rated transformers for switching power supply loads with extensive third harmonic conditions 2.5.6. Television tape archiving: A 3000-4000 square-foot vault is planned to archive over 40,000 historic tapes and provide tape storage for news and production. The strategic business plan for this space includes retrieval of tape until these programs become server-based and tape is completely phased out. The following diagram depicts the Tape archiving process into Server: TAPE ARCHIVING INTO SERVER: … High –speed bus TO Switch TAPE archive Optical Juke Box RAID Fig:5 Hardware architecture of a Video server 2.5.7.TAPE TRANSMISSION (FEED ASSEMBLY): The satellite communication of TV shows is transmitted through FEEDS. This is a cheaper and faster technology for sending Video TAPES or Stories. Feed from Production House to the NETWORK: The program is shot on film or videotape, and is then edited by a "Production House". When the program is done, it is then transmitted from U.K to European centers, where it is picked up and recorded by the network. In almost all cases, these shows are fed with NO COMMERCIALS. (2) Feed from MAIN station to Local Station This type of feed is used for Talk Shows, some Interviews, and stories prepared before. The stories that are played at the local station are sent to the main news studio through videotapes through feeds. Again, the local station will record the show for later broadcast A video server storage Hierarchy 2.5.8.MEANS OF CONVEYING COMMENTARY AND TEXT: The MIME type with RFC 1521 is proposed to be installed in the NEWS Studio for Type of message inclusions like- Rich or plain text, Gif or Jpeg Images, Basic Audio, Mpeg Video, Octet stream or Post script Application, MIME, RFC 822 message inclusion with split or total message fetch, Multi part technology for simultaneous view of different formats of RFC 822 message. 2.5.9.THE AUDIO VEDIO SYNCHRONIZATION AT TV STATION: MPEG-1:The audio encoder and Video encoder and a system Multiplexor will produce a MPEG-1 output. Audio signal MPEG-1 output Video signal Fig7: Audio Video Synchronization stream in MPEG-1 MPEG-2: For an MPEG-2 system output, Packetiser and Multiplexor are used for variable length and Fixed length packets Packetised elementary stream Video PS (Variable length Packets, common Time base) TS Audio (Fixed length Packets, no Common time base Fig8: Multiplexing of two streams in MPEG-2 3. TV STATION TECHNOLOGY: The proposed Tv studio include is planned to operate on the following Technology: AREAS SYSTEMS TECHNOLOGIES PRODUCTION Studio cameras HDTV cameras fitted with HDTV lenses, SDI output for SDTV. Vision/audio mixers Digital mixers, SDI and AES3. Virtual studios 3D virtual sets, using infra-red camera tracking. Monitors 16:9/4:3 switch able Intercom system Intelligent trunking system, for reliability Studio voting system Network based game-show system, custom designed. Graphics/CG/SS Networked workstations and 16:9 capable units POST-PRODUCTION Video, audio mixers Digital mixers, SDI and AES3. Audio, Video, text with commentary MIME with RFC 1521 Editing for News Digital online systems. SAN based NLE systems (with real-time audio punch-ins, 8 displayed audio tracks, in development) NETWORK Station network High speed fibre network among buildings, IP-based Media NET with Multiple Apllication-server storage farm. Audio-click free fibre interface system TRANSMISSION Master Control / Play out Satellite systems Digital multi-format routers, up gradable to HDTV Multi-channel server-based play out system, with automation. Central monitoring, using SNMP. Satellite farm (C and Ku bands), plus additional TVRO farms. TABLE 1 - Use of Technologies 4. STUDIO EQUIPMENT: The range of systems and equipment that are planned to use in the proposed TV studio, with extensive use of servers and networking PRODUCTION Studio Dimmers CompuDim 2000 Lighting Suspension TVB-custom suspension system Cameras HDC-900/ 950 HD and BVP-900P/ 950P SD cameras DVW 790-WSP field cameras DigiSuper 25XS Lenses V250-SS, Quattro Audio Mixers Alpha-100 56-ch PM1D 48-ch Sountracs DS-3 DMX-R100 Vision Mixers Golden DAVE 1.5ME (24-input) XtenDD10 and DD35 Kalypso 4ME CG/ SS Deko2200 dual-channel CGs Lightning-1000 dual-channel still stores Monitors BVM and PVM series Plasma Displays 42" standard Moving-Stay-Tune System DekoCast Logo Generators SAV LGA200DK Virtual Sets CyberSetNT 3D, for production and for news Transmission Trinix/ Venus routers, with Netcaptain monitoring system (SNMP-based) Digital interface system, with Roll-call monitoring system (SNMP-based) ADC-100 automation MSS 1600 Mediastream servers Nextream 4110 MPEG2 encoders Fibre interfaces with Vistalink monitoring system (SNMP-based) Evertz 7720 AES Audio Embedders/ De-embedders BEL 2120 and Junger b40 audio swappers Foxcom 7070D Transmitters/ Receivers MTS300 MPEG Test System Cavena Subtitling System Kaleido-2 Multi-viewers Intercom Telex Intercom, ADAM Networking Black Diamond 6808 backbone Unicenter Network Management System for security SUN-Fire 480 Servers (Database / Application / Web servers) News Avid Unity Media Network ENPS NRCS Harris Automation with Media Asset Management Table2: Studio equipment 5.COST SUMMARY OF DIFFERENT EQUIPMENT: ITEM PRICE in $ SECTION A. TRANSMISSION ATSC TRANSMISSION EQUIPMENT Low VHF (4kW avg SS High VHF 8kW UHF1 2.5 kW UHF2 15 kW UHF3 60kW 3,391,000 3,866,000 3,330,000 3,833,470 4,777,500 Standby Power generator and UPS $ 1,00,000 TRANSMIS -SION EQUIPMENT Low VHF 30 kW High VHF 45 kW UHF 60 KW 952,320 1,172,320 1,454,000 MASTER CONTROL Antenna Equipment 1,534,000 NTSC Equipment 188,500 OTHER TELEVISION EQUIPMENT 100-Watt UHF Translator Station (TV) $68,000 Portable HDTV Remote Package $211,300 Production Control and Studio Equipment (TV) $1,849,375 NTSC and DTV Television Test Equipment MASTER $106,475 XMTR $103,675 PBS Satellite Interconnect (KU Band TV) $112,284 PBS Satellite Interconnect (KU Band TV) Upgrade to Transmit $151,420 Television Videotape Editing System $345,000 Television Non-Linear Editing Station $177,000 ESTIMATEDTOTAL SET UP COST AT THE HIGH END 111,78,529 OPERATIONAL COSTS Cost of labor 365 *24 hrs *@ 20 $ 210240 Overheads 111 7852.9 Total 12506621.9 Note: The costing is an estimatory budget without land and building cost., and is for unlinking only. The cost of digital encoders, land and building costs are to be added to the above system 6. THE GANT CHART: The Project is supposed to start by June 1st week with a start up analysis. By the month of July the system is expected to gather its main resource persons to sit on the work. By the month of August ’05 the system is expected to be in a phase of Input out put design and planning. Parallel tot his the land and the facilities should be gathered and start its construction work by the month of August’05. And the system should start its equipment integration and facility works through January,2006. And by the month of June’06 the system acceptance and testing should be followed. The system should complete all its phases and should be ready to start its operations by the start of July’06 : RESOURCES: http://broadcast http://www.mlesat.com http//:www.shelburnefilms.com/index.html http://www.Tvtechnology.com/features http://www.broadcastpapers.com http://clearcom.com Read More
