Homodyne Receivers - Essay Example

The architecture of a homodyne receiver comprises the basic RF circuits which ensure the workflow of the equipment namely Band Select Filter (BSF), Low-noise amplifier (LNA), active mixer, oscillator and Channel Select Filter (HFS, 2008). LNA is an amplifier which converts the received signal to acceptable levels while minimizing the noise. (Varma,Kunder,Daruwalla,2003). The active mixers are responsible for frequency up-conversion and down-conversion functions (Beckwith, Schiltz, 2003) whereas Oscillator generates a series of waves which is mixed with the RF signals (Fukatsu, 2005). Channel Select Filter converts preferred low-power RF signals into significantly powerful ones.

The simplicity of its constitution and function is the prime advantage of this type of receiver. With relevance to the changing performance and functionality requirements for emerging technologies, the homodyne model becomes more practical to implement.

The major disadvantage of the homodyne receiver is that the down-converted signal is extremely sensitive to DC voltage offsets due to current leakage from the local oscillator entering into the LNA and mixer. This demands high requirements on reverse isolation and low substrate coupling. Moreover because of the down-conversion of the RF signal to zero IF, the noise in the oscillator must be minimized and the distortion or linearity must be kept very low for the LNA and mixer. This causes power dissipation as well (HFS, 2005).
