Architecture and Functionality of the Cisco 1006 Series Router - Lab Report Example

Full Paper Full Paper Architecture and Functionality Physical Architecture The physical architecture of the router comprises of SPA interface processor that can take up to 4 HH SPAs. Likewise, the SPA slots can be used for utilizing existing SPAs. Moreover, there is an embedded services processor that has 40 cores along with traffic manager. Further, there is a route processor that can support up to 16 GB DRAM with the speed of 2.66x2 GHz. In addition, there are other chassis options as well incorporating SPAs, SIP, ESP and RP. The route processor of the router has maximum speed of 1.5 GHz with a support of adding six routes (Newman, 2009). Likewise, this component also contains a hot swappable hard disk drive enclosure with a second generation route processor having speeds up to 2.66 GHz dual core Xeon processor. Moreover, the hardware architecture of the router has a built in forwarding quantum flow processor with the speed of 800MHz and operates on 10 Gbps (Joseph & Chapman, 2009). The SPA interface processor is constructed on first generation architecture with a 10Gbps aggregated performance with the speed of 800MHz. Figure 1.1 illustrates the differences between two models on different architectures below (Joseph & Chapman, 2009): ASR 1006 RP1 ASR 1006 RP2 CPU Freescale 1.5GHz Dual-Core Intel Xeon Processor 2.67GHz Memory Memory 2GB default 2x1GB) 4GB maximum (2x2GB) RP1 with 4GB built in ASR1002 and ASR1002-F 8GB default (4x2GB) 16GB maximum (4x4GB) e-USB bootflash Built-in eUSB bootflash 1GB (8GB on ASR-1002 and ASR1002-F) 2GB NVRAM 32 MB 32 MB Hard Disk 40 GB 80 GB Support for Chassis ASR 1002 (built-in), ASR 1004 and 1006 ASR 1006 and 1004 Cisco IOS Operating System 32 Bit 64 Bit Figure 1.1, Architecture Comparison The building blocks of the router comprises of following components: Hardware Architecture RP: The route processor has a separate 1.5 Ghz central processing unit with a maximum support of 4 GB DRAM. Moreover, NVRAM comprises of 32 MB memory along with a 1 GB on board flash. The management interfaces incorporates a manageable Ethernet port, an auxiliary port and port dedicated for console. For storage, there is a rotatory hard drive with a capacity of 40 GB. The functionality of the processor communicates with channels and cards, as these two are managed by ‘network packets controlling’ function. Likewise, the network clock and the BITS reference input are utilized for SONET link synchronization. Apart from these features, there are miscellaneous control functions including power controls, alarms, card detection etc. (Francis, 2004). ESP: This is a forwarding processor that is centralized and uses a programmed forwarding engine supporting full packet processing. Moreover, this component also supports buffering along with scheduling for traffic directed to carrier cards such as SPAs and the other use of this component links to special features i.e. re-assembling, shaping of inputs, duplication etc. Further, the interconnectivity that is between data path links transmits traffic in and out of QFP and the scheduler that work for allocating QFP between ESI’s. In addition, this component also supports cryptography, mid plane links etc. SPA / SIP: The SPA interface processor is capable of supporting 4 SPAs, however, there is a limitation, as it does not participates in forwarding. Likewise, this component supports limited quality of service, as the mechanism can identify low and high packet classification. Moreover, there is also a support of 128 MB oversubscribed buffering (Lucas, 2009). For getting detailed information for the dropped packets, this component provides statistics on the packets that are dropped. Likewise, the mid-plane links are managed by SIP central processing unit Behavior & Performance Fig 1.2 links the functionality of the router with the IOS and hardware resources along with the benefits that can be achieved. Features of IOS Hardware Resource Paybacks Access Control List (ACL) Range lookup for ACL and TCAM The lookup is robust with no service degradation uRPF Unit for pointer look up uRPF is enabled that facilitates minor service degradation NAT Session Lookup Hash mode is set to read In spite of having large number of sessions, performance is not affected Policing PPE and QFP DDOS prevention by enabling CoPP with no service impact IPSec Crypto Engine A built in high tech multi core chip that handles the service impact and assures minor latency Figure 1.2 These two components are essential for delivering acceptable service levels to the business. Likewise, the redundant network not only maintains the service quality in normal situations but in critical situations as well. For instance, a link has failed to respond and it needs to be rerouted from the faulty route to an operational and active route. Supporting this feature requires an aggregation service supported router with next generation processing capabilities. Likewise, Cisco has established a Quantum Flow Processor that is the first combined chip that can be re-programmed. Moreover, the processor supports a large scale parallel processing with quality of service, next level memory management and re programmable integrated services. With all these features, this router commands in service implementation and scalability leading to a minimized implementation time with low cost of ownership. The Wide Area Services edge facilitates robust and high data rates on the ASR 1006 series. In addition, the ASR 1006 provides optimization in terms of redundancy allocation for routers that maintain high availability. Figure 1.3 demonstrates the number of active routers against the number of standby routers. Fig 1.3 Sources: (Buggey, 2007) Following are the factors that are directly proportional to accomplish and assist business objectives (Chen, H., Li, F. H., & Xiao, 2011): Considerable raise in WAN bandwidth and volume, when compared to previous router series. Enhanced security features by activating Cisco Webex node on the router along with Unified border element and high definition multimedia content, Public switched telephone networks (PSTN), application performance optimization etc. A redundant link available for maintaining connectivity over the WAN in case of primary link failure Alternate power sources ensure operational continuity and contingency planning on its own. Robust hardware architecture bundled with data split-up and control for system availability Contingency is also available for route processing and route forwarders in case of failover initiation Redundancy for Cisco IOS that can be operated on a non-redundant hardware Remote access for router to restart or remove any fault that may arise via In services software upgrade A high tech security mechanism is available for countering attacks and act as a preventive control along with ensuring compliance Security mechanism activation do not affect the performance of route processing and other associated services The simple holistic configuration approach saves cost, time and resources for the organization The privately established remote sites are secured by aggregation mechanism built in the router Encrypted Internet access, firewall and virtual private network services are also considered as an enhanced security feature Conclusion The report has primarily discussed about the physical and hardware architecture of the Cisco 1006 series router. Likewise, individual performance and functionality for each component of the router is demonstrated along with a comparison and a benefits table for elaborating the topic and to link it with its real benefits i.e. business objectives. Lastly, the fact was established and was associated with the features, functions and services with a realistic scenario of assuming and linking them with the organization’s objective i.e. availability of service, quality of service, security and redundancy. References Chen, H., Li, F. H., & Xiao, Y. (2011). Handbook of Security and Networks. Hackensack, NJ: World Scientific. Francis, B. (2004). Cisco Routers Add Services. Infoworld, 26(37), 19. Joseph, V., & Chapman, B. (2009). Deploying QoS for cisco IP and next generation networks: The definitive guide Elsevier Science Lucas, M. (2009). Cisco routers for the desperate [electronic resource] : router and switch management, the easy way / Michael W. Lucas. San Francisco : No Starch Press, c2009. Newman, D. (2009). Ciscos ASR router: A strong first effort. (cover story). Network World, 26(2), 1. Images: Buggey,T ( 2007) Storyboard for Ivans morning routine. Diagram. Journal of Positive Behavior Interventions, 9(3), 151. Glossary SPA: Shared Port Adapter BITS: Building Integrated Timely Supply QFP: Quantum Flow Processor ESI: Enhanced SerDes Interface Read More
