The pin plate is sliding surface. The manufacturing of this object is possible through different means. In this article the manufacturing of the object through casting has been discussed. The quality checks prior and after machining have been discussed.
The CNC machine will be useful in the formation of the die for the moulding of the pin plate…
Download full paperFile format: .doc, available for editing
GRAB THE BEST PAPER93.3% of users find it useful
Pinplate Manufacturing,
Read TextPreview

Extract of sample
"Pinplate Manufacturing,"

Download file to see previous pages The constituents of the material shall be verified, and any variance shall be judged. The requirement for dye penetrant testing and flaw detection is not essential, as the material has to be melted.
The manufacturing of the Pin Plate is recommended through Die Casting. The Die Casting is manufacturing process for the production of units with high dimensional accuracy, and appropriate surface finish. The desired material for the Pin Plate, should be inserted into steel mould under high pressure, the material shall be molten. The vents shall be provided in the mould to prevent formation of air gaps. The molten metal should be poured through feed system, which shall be pump the molten material into the mould. After the insertion of molten material inside the mould, the pressure on the mould is increased during solidification. During this process of fabrication of pin plate, the formation of jig has been critical step. The formation of die includes machining of the die, and its lubrication. The required material for the pin plate should be melted, and the formation of the oxidized metal can be prevented through scrapping. After the completion of casting, the machining and cleaning processes are initiated to remove the "traces of the feed system and flashing".
The casting of the pin plate can be possible in two diff...
The casting process can be summarised as, "the die halves are first locked into the machine and the plunger retracted, as the molten metal is ladled into the shot chamber by way of a pouring hole; the plunger is moved back into the chamber, forcing the metal into the cavity". The material remains under high-pressure, and sufficient time shall be provided to the material for solidification. After the solidification of the molten material into pin plate is achieved, "the die is opened and plunger returned to its initial position".
The finishing process includes the detachment of the pin-plate from the die. It is important to understand that the "flashing and the extra cast bits of the feed system" are still attached to the job-piece which shall be removed through machining. The machining of the pin plate is recommended on the lathe machine to achieve dimensional accuracy, and to remove extra bits of the feed system, runner and overflows. It is recommended that the finishing of the object shall be conducted through band saw and cut-off wheels, the pin-plate; the object piece shall be then cleaned by application of abrasives, or pressurized water.
Machining Program
The discussed machined program shall be applied on the die for casting,
N10 G00 G19 G34 G56 G80 G90 G98
N12 T3 M06
N14 S10000 M03
N16 G00 G54 G43 X0.5 Y0.2 Z1. H03 M08
N18 Z0.4
N20 G99 G81 Z-.2 F12.
N22 M97 P1000
N24 M09
N26 T4 M06
N28 S3761 M03
N30 G00 G65 G45 X2.25 Y0.5 Z0.5 H04 M08
N32 Z0.1
N34 G99 G73 Z-1. R.05 Q.1 F18.
N36 M97 P1000
N38 M09
N40 T3 M06
N42 S1000 M03
N44 G00 G54 G43 X2.25 Y0.5 Z2. H03 M08
N46 Z0.5
N48 G99 G84 Z-.1 R.05 F50.
N50 M97 P1000
N52 M09
N54 G91 G28 Y0 Z0
N56 G90
N58 M30
N1000 (P1000: HOLE PATTERN)
N1002 X0.4 Y0.2
N1004 X0.6 Y0.2
N1006 ...Download file to see next pagesRead More
