Network Security - Research Paper Example

Comments (0)
Summary
Differentiated Services Field is not set. This byte was originally called the Type of Service (ToS) byte, but was redefined by RFC 2474 as the DS Field. It is used for marking packets for the purpose of applying different quality of service (QoS) levels to different packets
Download full paper
GRAB THE BEST PAPER
Network Security
Read TextPreview

Extract of sample
Network Security

Download file to see previous pages... Differentiated Services Field is not set. This byte was originally called the Type of Service (ToS) byte, but was redefined by RFC 2474 as the DS Field. It is used for marking packets for the purpose of applying different quality of service (QoS) levels to different packets
Differentiated Services Field is not set. This byte was originally called the Type of Service (ToS) byte, but was redefined by RFC 2474 as the DS Field. It is used for marking packets for the purpose of applying different quality of service QoS) levels to different packets
Differentiated Services Field is not set. This byte was originally called the Type of Service (ToS) byte, but was redefined by RFC 2474 as the DS Field. It is used for marking packets for the purpose of applying different quality of service (QoS) levels to different packets
Differentiated Services Field is not set. This byte was originally called the Type of Service (ToS) byte, but was redefined by RFC 2474 as the DS Field. It is used for marking packets for the purpose of applying different quality of service QoS) levels to different packets
Differentiated Services Field is not set. This byte was originally called the Type of Service (ToS) byte, but was redefined by RFC 2474 as the DS Field. It is used for marking packets for the purpose of applying different quality of service (QoS) levels to different packets
+ One http connection was reset by the client itself even after gett...
Packet 6
1. Destination IP address mentioned in the description block 10.63.129.199 does not match with the IP address actually communicated in the packet ie 192.168.246.1
2. The host rejected the connection by sending RST flag instead of sending SYN, ACK flag. This indicates the destination host is not willing to initiate inbound connection on port 139.

Packet 7
1. Source IP address mentioned in the description block 10.63.129.199 does not match with the IP address actually communicated in the packet ie 192.168.246.1
2. Packet length mentioned in the description block is 40 while actual bytes mentioned are 46


Detailed Description of Packets:
Packet # 1

20:52:50.764815 IP (tos 0x0, ttl 46, id 18251, offset 0, flags [none], length: 44) 10.63.129.199.49206 > linux-server.ssh: S [tcp sum ok] 1304132321:1304132321(0) win 3072

0x0000: 4500 002c 474b 0000 2e06 d821 c0a8 f601 E..,GK.....!....
0x0010: c0a8 f60c c036 0050 4dbb 7ae1 0000 0000 .....6.PM.z.....
0x0020: 6002 0c00 95a3 0000 0204 05b4 0000 .............


Bytes of the trace
Breakdown in bits where necessary
Description and significance
45
0100 0101
1st 4 bits represent IPv4; next 4 bits represent 5 double words long IP header (ie 20 bytes header).
00

Differentiated Services Field is not set. This byte was originally called the Type of Service (ToS) byte, but was redefined by RFC 2474 as the DS Field. It is used for marking packets for the purpose of applying different quality of service (QoS) levels to different packets
002c

Length of the Layer 3 packet is 44 bytes
474b

Identification value is 18251. This value helps in assembling fragmented packets
0000

IP header flags ...Download file to see next pagesRead More
