Machine Production Records - Case Study Example

The rated production rates for machine types 1, 2, and 3 were 700, 200, and 155 parts per minute, respectively, but actual production rates varied. Helen felt that factors such as quality of input material, worn or "changed-out" dies, and dirty or poorly maintained presses would probably affect production.

The facility had always kept daily production records, but from what Helen could tell, no one ever consulted them or did anything with them other than to put them in file cabinets at the end of each reporting period.

The machines were scheduled for a shift of 7.75 hours each day. The operators recorded the hours of operation manually on clipboards kept near each machine. The actual quantities of parts produced were determined from automatic counters on the machines. The data on the next two pages (and in file PROD) were derived from these logs.

Can you advise Helen?

 This case is based on a real production line situation, though the name of the organization and the exact nature of the product have been disguised. The data were provided by Ted Manzanares.

Solution

There are three variables that present the problem: The no. of parts produced the no. of hours that they spent and the number of hours when the press was down.

We compute the deliverable statistics.

M type

Frequency

Percentage

700

28

24.1

200

35

30.2

155

53

45.7



116

100.0

Statistics for the variables.

Variable

Statistics

Value

No. of parts produced

Mean

97610.26



Median

58707.50



Variance

9600782707.9



Standard deviation

97983.584



Standard error

9097.547



Minimum

5084



Maximum

320242



Interquartile range

57286

Hours of production

Mean

5.7784



Median

6.8300



Variance

4.886



Standard deviation

2.21045



Standard error

0.20524



Minimum

0.58



Maximum

7.75



Interquartile range

4.06

Hours press was down

Mean

1.4859



Median

0.5400



Variance

3.422



Standard deviation

1.84984



Standard error

0.17175



Minimum

0.00



Maximum

7.17



Interquartile range

2.67



Statistics for each type

Variables

M type

No.

Mean

Standard deviation

Standard error



1

28

259627.54

58444.892

11045.046



2

35

43210.43

17238.352

2913.813



3

53

47940.64

24976.660

3430.808

Total



116

97610.26

97983.584

9097.547

Hours of production

1

28

6.7668

1.38309

0.26138



2

35

5.8906

2.16969

0.36674



3

53

5.1821

2.41612

0.33188

Total



116

5.7784

2.21045

0.20524

Hours that press was down

1

28

0.9593

1.35500

0.25607



2

35

1.8594

2.16969

0.36674



3

53

1.5175

1.81441

0.24923

Total



116

1.4859

1.84984

0.17175



Highest and lowest values in each variable

Value



No. of parts produced

Highest = 320242

316080



315124



312501



311877



Lowest

5084

6899



8142



8675



8954



Hours of production time

Highest 7.75

7.75



7.75



7.75



Lowest

0.58

0.58



1.08



1.08



1.08



Hours that the press was down

Highest 7.17

6.25



6.00



5.83



5.58



Lowest

0.00

0.00



0.00



0.00



0.00





Based on the statistics above, we can advise Jane for a machine type to be considered as being effective, it must be able to produce parts that are between 5084 and 320242 in number. The machine type must also be able to operate a minimum of 0.58 hours and a maximum of 7.75 hrs. From the statistics of central tendency, machine type 2 is the best for producing parts and also uses minimum time. When the press was down, machine type 2 is the best since it has the minimum standard error.
