Elemental Cost Plan for Commercial Office Development - Research Paper Example

Total steel/ metal required is approximated to be around 300 kgs .This done taking into consideration that CPA is 951.6 sq.mtr .Labor cost is assumed to be 16 pounds/ sq.mtr for entire work. Equipment charges are assumed to be around 3000 pounds Material cost = 400 x 30=12000 pounds Labor charges = 16 x 951.6=15225.6 pounds Total cost = 12000 + 15225.6 +3000=30225.6 pounds Total masonry and concrete required per sq.mtr is assumed to be 0.

6 kgs per sq.mtr. Labour charges for entire work are assumed to be around twice the material required. Material cost = 0.6 x 951.6 x (64 +5) =39,396 pounds Labor charges = 2 x 39396 = 78792 pounds Total cost = 39396 + 78792 =118188 pounds Total area to be insulated is approximately around 1000 sq m. This includes all external walls .The area is calculated from the available drawings. The rate of insulating material is taken 8 pounds /sq.mtr from the above table.

Labor charges are taken to be around 4000 pounds for above project. Total cost = 8 x 1000 +4000=12000 pounds Total number of doors of ground floor = 32 No of doors on first floor =25 . Insulation :- Total area to be insulated is approximately around 1000 sq m.

This includes all external walls .The area is calculated from the available drawings. The rate of insulating material is taken 8 pounds /sq.mtr from the above table. Labor charges are taken to be around 4000 pounds for above project. Total cost = 8 x 1000 +4000=12000 poundsDoors and windows:- Total number of doors of ground floor = 32 No of doors on first floor =25 Number of windows = 53 Wood work rate is 114 pounds / sq mtr.

Assuming 100 pounds are required to make one door and 100 pounds to make one window. These include material and labor charges. Total cost = 55 x 100 + 53 x 100 = 10,800 pounds.Exterior trim and finish:- Total exterior area is approximately 480 sq. mtr. Material rate is assumed to be 50 pounds/sq.mtr Labor rate is taken as 27 pounds / sq.mtr. Material cost = 480 x 50=24000 pounds Labor charges = 480x 27=12960 pounds Total cost = 24000 + 12960 =36960 poundsGable roof rafters, Gable roof trusses, Gable roofing:- Total roof area is calculated and comes out to be 415 sq.

mtr approximately. The rate is from the table is 37 pounds /per sq.mtr. pounds for gable roof rafters, roof trusses and roofing.
