1) The Open System Interconnection (OSI) reference model was developed by the International Organization for Standardization (ISO) in 1984 as a conceptual model composed of seven layers (or stacks), each specifying particular network functions. Each layer is subdivided into task groups and each layer can be implemented independently of the others which is important if one layer is to be upgraded…
Download full paperFile format: .doc, available for editing
GRAB THE BEST PAPER94.1% of users find it useful
Open System Interconnection (OSI)
Read TextPreview

Extract of sample "Open System Interconnection (OSI)"

Download file to see previous pages The data transport or 'lower layers' of the OSI model handle data transport issues and are implemented in hardware and software. The lowest layer, the physical layer, is responsible for actually placing information on the medium. As a side note, most systems today use a modified version of this model; for example TCP/IP uses a 6-layer model.
The OSI model is generic and is not a communication model -it makes no assumptions about programming language bindings, operating system bindings or application and user interface issues. Communications are implemented through protocols which are a formal set of rules and conventions that govern how computers exchange information over a network medium. A protocol implements the functions of one or more of the OSI layers. The table below describes the role of each of the 7 layers in greater detail:
Responsible for activating, maintaining and deactivating the physical link between network objects. Network interface cards and interfaces on routers run at this level. Physical layer specifications define characteristics such as voltage levels, timing of voltage changes, physical data rates, maximum transmission distances, and physical connectors. Physical layer implementations can be categorized as either LAN or WAN specifications.
When an application on Computer 1 sends dat...
Provides error checking, error recovery and flow control. The transport protocols used on the Internet are TCP and UDP.
3
Network Layer
Makes the upper layers independent of the data transmission, switching technologies, and topology of the network. Determines which path(s) in the network that data will be routed.
This layer is very important to the design and configuration for internetworking. IP and routing protocols operate here.
2
Data Link Layer
Provides reliable transfer across the physical links. Establishes the beginning and end of blocks of data (with synchronization when necessary)
Reorder frames which are out of sequence [framing];
error detection and correction
rate of data transmission [flow control].
It is subdivided into the logical Link Control (LLC) and Media Access Control (MAC) sub layers. Bridges and switches interface here.
1
Physical Layer
Responsible for activating, maintaining and deactivating the physical link between network objects. Network interface cards and interfaces on routers run at this level. Physical layer specifications define characteristics such as voltage levels, timing of voltage changes, physical data rates, maximum transmission distances, and physical connectors. Physical layer implementations can be categorized as either LAN or WAN specifications.
electrical
optical
mechanical
When an application on Computer 1 sends data to Computer 2 that data passes through each layer of the OSI model on Computer 1 until it gets to the Physical layer. At that point it is transmitted on the physical medium (e.g. cabling) across to the Physical layer on Computer 2. The data then passes up through the Physical, Data, Network, Transport, Session, Presentation and ...Download file to see next pagesRead More
