Effective troubleshooting is a stepwise procedure that can be modified depending on the system that is being dealt with. The basic steps of troubleshooting, as I discovered, start with identifying the defect system. This enables the person identify whether the problem is I the electrical circuit, or if the problem is mechanical. The second step in basic troubleshooting is analysing the fault in the identified system. The third step of troubleshooting is carrying out of repairs. With these three steps, the setback has been identified and sorted out (Electrical Circuit Theory).

Considering that there a number of problems that are encountered, I narrowed my scope of study to electrical troubleshooting. Troubleshooting an electrical circuit has its own procedure. It is a modification of the basic process of troubleshooting, to suit the system in issue. In any given electrical circuit, it is important to identify what the controls and loads are. This is the first step in troubleshooting electrical circuits. Electrical circuits are put into two groups; the power, and control circuits.

I realised in my hunt that it is crucial to understand both of these circuits consist of the power supply, and the switches and/or controls. In addition, circuits will also have one or more loads, and the path that the current will follow. These four components of a circuit could be the source of the problem experienced. After this, I realised that it is necessary for the sequence of operation of the system be properly understood. Every step involved, proper understanding is crucial since lack of the same can lead to gross errors.

This will help a technician have a clear knowledge of how the system should work. In the occasion that the system is not operating like it should, the technician will be able to point out the problem with the circuit (Brown, Rawtani, & Patil, 2004). The third step in this process is application of
