Determining the high-level architecture. Creating a detailed design. Monitoring progress during system development. Providing a successful implementation. Creating the acceptance test plan for the completed system.System overview The purpose of this High-Level Design document is to add, the required detail, to the recent project report to represent a suitable model for the circuit. System architectural design The wireless has an exposed antenna. This antenna serves the purpose of boosting transmission of the trigger towards the movement of the fan.

The components would be light and not jammed because there is a meager use of connecting wires. It is vital to note that the switches will possess an indirect link to the decoder. This is to enable the usability of switches. In addition, the switches will possess an angle of 90 degrees to the motor. This is to enable the compatibility of the switches to the motor fan. It is vital to note of the idea that the wireless fan system possesses two core components. These two components have more than a functional separation.

The core parts possess a physical and functional separation between the sending and receiving components. This has a first antenna and a second antenna that link to transmit signals between the same. The decoder is segregated to send and receive signals through the system of antennae. The antennae have a relationship between the two links in the sense that the two signals shift between entities. Therefore, the decoder connects to the motor that rotates to trigger the movement of the blades. Traceability The system has four switches that connect to the four sections of the decoder.

The decoder connects to the antenna and the LDE. In this sense, the antenna sends a signal to the receiving antenna. The antenna transmits a signal that triggers three levels of the decoder. The decoder, thus, transmits a signal to the motor that rotates.
