Hardware Lab Equipment 1. What kind of equipment did you get? I received Wireless-N Broadband Router. 2. What is the make and model of this equipment?
The equipment is manufactured in China by LinkSys –Cisco Systems. Its model no is WRT 300 N V1.1.
3. What is the MAC / hardware address of this equipment?
The MAC address of the equipment is 001D7EE52288
4. What types of interfaces does this equipment have?
This device has five Ethernet ports. One of then is for the input Ethernet and four ports are for the output Ethernet. It has a wireless connectively with computer’s W-LAN or wifi device. One port is for the power adapter that provides 12 volts and 1 ampere current.
Equipment #2
1. What kind of equipment did you get?
I have received Cisco Catalyst 3550 Series that is a network switch.
2. What is the make and model of this equipment?
The equipment is manufactured by Cisco and its model no is WS-C3550-48-SMI.
3. What is the MAC / hardware address of this equipment?
The MAC address of the equipment is 000F:23:23:2F:00
4. What types of interfaces does this equipment have?
The equipment has two fast Ethernet in/out ports. On the other hand, the equipment has 48 connectivity Ethernet ports. One power supply port is also there. Two ports are for the serial out and serial in.
5. Does this equipment support add-on modules? What kind(s)?
The equipment does not allow the users to install any add-on modules.
Equipment #3
1. What kind of equipment did you get?
I got a Cisco 2600 series Multiservice Platform that is a Modular multiservice access router that provides flexible LAN or Ethernet configuration.
2. What is the make and model of this equipment?
The equipment is manufactured by Cisco systems and its model number is CISCO 2621XM.
3. What types of interfaces does this equipment have?
The equipment has one Auxiliary port, One ETHRENT 0/0 10 base-T port (RJ-45), one Ethernet 0/1 10 base-T port (RJ-45). On the other hand, the link and act LED indicators show the process of communication.
4. Does this equipment support add-on modules? What kind(s)?
The equipment also allows the users to install more Ethernet interface cards.
Task 1: 10 GbE is still in its infancy stages, so the specifications of the various media and interfaces are still in development. Using various resources such as the textbook and the Internet, research and document the following implementations of IO GbE:
1. 10GBase T Cabling:
Cable Details:
Cat 6a, Cat 7 twisted pair, Coaxial cable, fiber optics,
Connectors:
RJ-45
Length:
300m
2. 10GBaseSR/SW Cabling
Cable Details:
Cat 6a, Cat 7 twisted pair, Coaxial cable, fiber optics
Connectors:
RJ-45
Length:
65 meter for fiber cable
3. 10BaseLR/LW Cabling
Cable Details:
Cat 6a, Cat 7 twisted pair, Coaxial cable, fiber optics
Connectors:
RJ-45.
Length:
For fiber cable 10Km
Works Cited
Meyers, Michael, Scott Jernigan, and Glen E Clarke. Comptia Network+. 1st ed. New York: McGraw-Hill, 2012. Print. Read More
