Side-Draft Carburetor A side-draft carburetor is a device that blends fuel and air fo the internal combustion engine. This paper gives a description of the Solex PICT-2 carburetor system. This fuel system consists of a front mounted fuel tank that is linked through the line to the fuel tank. The carburetor also consists of an eccentric cam positioned on the distributor drive shaft. The eccentric cam operated the mechanical fuel pump which is responsible for delivering fuel.
Solex PICT-2
1
Carburetor upper half screw
13
Diaphragm spring
25
Spring
2
Spring washer
14
Diaphragm
26
Pilot jet cutoff valve
3
Carburetor upper half
15
Gasket
27
Circlip
4
Float needle valve
16
Accelerator cable return spring
28
Fillister head screw
5
Needle valve washer
17
Carburetor lower half
29
Pump cover
6
Retaining ring screw
18
float and pin
30
Pump diaphragm
7
Retaining ring
19
Float pin bracket
31
Diaphragm spring
8
Retaining ring spacer
20
Air correction jet
32
Cotter pin
9
Automatic choke
21
Main jet plug
33
Washer
10
Plastic cap
22
Plug seal
34
Connecting rod spring
11
Fillister head screw
23
Main jet
35
Connecting rod
12
Diaphragm cover
24
Volume control screw
36
Accelerator pump injector tube
Positive things about side-draft carburetor
The side-draft carburetor contains jets that will push the gas into the burning chambers. The measure of fuel that can course through the jets rests on the amount of air that can be pulled into the carburetor wander. The fundamental issue with acquiring the best execution utilizing a carburetor is that it cannot screen the air to fuel proportion for every individual barrel. In the event that there was a carburetor for every barrel, this would not be an issue. So with a carburetor, the best fuel to air proportion for every chamber is approximated for the best execution (Leffingwell, 2012).
Nevertheless, carburetors do last more than fuel infusion systems and are supported in engine sports. Carburetors are additionally much less complex to introduce than fuel infusion systems, because there are no electrical segments or return lines to the fuel tank. The carburetor is presently substantially less costly than the electronic fuel infusion systems.
Negative things about side-draft carburetor
Negatively, at a low speed, the mixture supplied by a side-draft Carburetor is weak to the point that it wont light appropriately and for its advancement, at such conditions some course of action in the carburetor is obliged to be made. The working of side-draft carburetor is influenced by changes of barometrical weight (Gunnell, 2011). Carburetors utilized as a part of the airship are to be given height control as the rich mixture is unnecessarily accessible, because of less thickness of the air.
In addition, the working of side-draft carburetor is influenced by changes of environmental temperature. In the event that the setting is carried out in winter season, it will be found to give excessively rich mixture in the late spring. This happens because of less thickness of air with the ascent of temperature to a grater degree than the thickness of fuel (Gunnell, 2007). It gives the best possible mixture at stand out motor speed and burden, in this way, suitable just for motors running at steady speed build or diminishing ,the amount of fuel issuing out will change and not match the speed of air moving through the venturi and legitimate mixture is not occur. To conquer these different changes must be made in side-draft carburetor.
Three positive things about Downdraft carburetor
Downdraft carburetor massively lessens fire risk by taking carburetor up out of the bilge. Secondly, in case the engine oil pressure systems becomes faulty, the Downdraft carburetor inevitably shuts off the underlying fuel supply thus saving any probable damage that may develop due to lack of lubrication. Thirdly, Downdraft carburetor positively promises a minimum escalation of 150 engine revolutions in every minute by attaining revolutions as high as 300.
Three negative things about Downdraft carburetor
Adjustment of a modern downdraft carburetor for the leaner mixtures demands disassembly and corresponding replacement of fixed jets with the new jets possessing a slightly smaller orifice. Secondly, Downdraft carburetor has a slow performance results to too lean fuel air mixture. Thirdly, lean mixtures of the downdraft carburetor occasionally make the engine waver; cough and corresponding fire back via the carburetor.
References
Gunnell, J. (2007). Standard catalog of Jaguar, 1946-2005. Iola, Wis: KP.
Gunnell, J. (2011). Standard catalog of Chevrolet, 1912-2003: 90 years of history, photos, technical data, and pricing. Iola, WI: Krause Publications.
Leffingwell, R. (2012). Corvette: Sixty years. Minneapolis, Minn: Motorbooks. Read More
